Description
[Features]
1. Latest Microprocessor Controlling System
One button auto zero calibration and 100%T calibration.
128*64 LCD display, direct readout of Transmittance, Absorbance and
Concentration.
2. Precision 1200 lines/mm Grating Monochromator
Ensure high photometric resolution, high accuracy and low stray light.
3. Easy Data Output by USB/Parallel Port
USB Port: Connect to computer and operate through PC software. ( PC software
is optional.)
Parallel Port: Connect to micro thermal printer to print test data. ( Micro
thermal printer is optional.)
4. Wide Sample Chamber Enables Multi-functions
120mm wide sample chamber and long optical path monochromator provide enough
space for optional accessories.
5. Four Display Modes; One-Button Quick Switching
Transmittance, Absorbance, Concentration and Factor (Coefficient) mode.
[Technical Specification]
|
Model |
V-5000 |
|
Optical System |
Single Beam, grating 1200 lines/mm |
|
Wavelength Range |
325-1000nm |
|
Spectral Bandwidth |
4nm |
|
Wavelength Accuracy |
±2nm |
|
Wavelength Repeatability |
≤0.5nm |
|
Wavelength Setting |
Manually |
|
Photometric Accuracy |
±0.5%T |
|
Photometric Repeatability |
≤0.2%T |
|
Photometric Range |
-0.3-3A, 0-200%T, 0-9999C |
|
Photometric Mode |
T, A, C, F |
|
Stray Light |
≤0.2%Tat 360nm |
|
Display |
128*64 Dots LCD |
|
Detector |
Silicon Photodiode |
|
Output |
USB Port & Parallel Port |
|
Light Source |
TungstenLamp |
|
Power Requirements |
AC85~250V |
[Standard Accessories]
|
Item |
Description |
Quantity |
Unit |
|
1 |
Spectrophotometer |
1 |
unit |
|
2 |
1cm Glass cuvette |
4 |
pcs |
|
3 |
Power cord |
1 |
pcs |
|
4 |
User’s manual |
1 |
pcs |
|
5 |
Black block |
1 |
pcs |
|
6 |
Dust Cover |
1 |
pcs |
